1092mm Small Size Economic Price Toilet Tissue Paper Making Machine Paper Manufacturing Machine

tissue paper making machines for the whole production line
  • 1092

  • FRD

  • 2-3 tons per day

  • 60-110 m/min

  • 150m/min

  • 1800mm

  • Toilet paper,tissue , facial tissue paper, napkin paper...

  • 1092mm

  • 13-25gsm

  • AC frequency sectional drive

Availability:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
sharethis sharing button

1092mm small size economic price toilet tissue paper making machine paper manufacturing machine

paper making machine

Product Description of paper making machine

Technical parameter

Paper Type: Toilet Paper

Basis Weight: 13-30g/m²

Paper Width: 1092mm

Cylinder Width: 1450mm

Design Speed: 150m/min

Operating Speed: 60-110m/min

Production Capacity: 2-3 tons/day

Gauge: 1800mm

Pulp Handling: Downside hanging pulp

Drive System: AC variable frequency and stepwise transmission

Machine Design: Square box structure, right-hand operation


Main structure of paper making machine:

  1. Cylinder Wire Section:

    • One cylinder mold: Ø1000mm×1450mm

    • One couch roller: Ø300mm×1450mm, with rubber hardness of Shore 380±2

    • Equipped with one net cage

  2. Dryer Section:

    • One dryer: Ø1500mm×1450mm

    • One touch roller: Ø350mm×1500mm, with rubber hardness of Shore 950±2

    • Mechanical pressure system

  3. Reeling Section:

    • One paper reeling roller: Ø500mm×1450mm

    • Equipped with roll stand and two roll bars per set


 微信图片_20210906164735

Buying Guideof choosing paper making machines:


           In order to recommend proper machine and make detailed technical proposal for you as soon possible ,please tell us the following technical parameters:

(1)what kind of paper do you want to produce?

(2)what kind of raw material you will use?

(3)how many tons do you want to produce per day(24hours)?

(4)what is the output paper width of jumbo roll?--mm;

(5)What is the output paper weight(thickness)?--gsm.
